Description
Compact High Speed Recovery System for Competition Use
The RS9 S platform is built specifically for high speed recovery in UTV and buggy class vehicles where every kilogram and every second matters.
Its 8HP series wound motor is paired with an 80 to 1 heavy duty gear system that prioritises fast line retrieval under load. This allows operators to reduce recovery time significantly during racing, winch challenges, or fast paced off road recovery situations.
Unlike traditional winches that focus on brute force alone, the RS9 S is engineered for speed efficiency without sacrificing structural integrity.
Short Drum Design for Tight Mounting Spaces
The shortened chassis and drum design allow installation in narrow front end configurations commonly found in race buggies and compact UTV platforms.
Despite its reduced footprint, the system retains full 9000lb rated pulling capacity, ensuring no compromise in recovery strength while improving vehicle balance and front axle load distribution.
Built for Race Buggies UTVs and High Performance Off Road Builds
The RS9 S is purpose built for competitive and high demand environments where recovery speed directly impacts performance.
Reinforced internal components and a lightweight chassis structure ensure durability under repeated high load cycles while maintaining consistent operation in aggressive terrain conditions.
This makes it ideal for rally support vehicles, UTV racing platforms, and custom off road builds where reliability under pressure is critical.
High Strength Synthetic Rope Recovery System
The RS9 S is equipped with an 8mm Spectra fiber UHMWPE synthetic rope system designed for high strength and controlled recovery performance.
The rope provides excellent abrasion resistance and low weight handling characteristics, improving usability during fast recovery operations. The 24 metre length allows flexible anchoring options in racing and remote recovery scenarios.
Engineered for Extreme Off Road Conditions
With an IP68 rated sealed system, the RS9 S is designed to operate in water, mud, dust, and high vibration environments commonly encountered in competitive off road use.
The sealed motor and electrical system ensure consistent performance even under repeated exposure to harsh terrain conditions. This level of protection reduces downtime and improves operational reliability in demanding environments.
Key Specifications
- Rated line pull 9000lb 4080kg
- Motor 8HP 12V series wound
- Gear ratio 80 to 1 heavy duty planetary
- Rope 24m x 8mm Spectra fiber UHMWPE
- Weight 22kg
- Dimensions 385mm x 115mm x 120mm
- Mounting pattern 164mm x 114.3mm
- IP rating IP68 waterproof and dustproof
- Included hardware MegaPro hook fairlead wiring kit
What is Included
- Carbon Offroad RS9 S 9000lb short drum winch
- 24m Spectra fiber synthetic rope
- MegaPro winch hook
- High strength fairlead
- Wiring and accessory installation kit
Installation and Fitment
Designed for Performance Off Road Platforms
The RS9 S is designed for race buggies, UTVs, and compact off road platforms requiring high speed recovery capability in a reduced footprint.
Professional installation is recommended to ensure correct mounting alignment, electrical integration, and safe load handling during high performance use.
Ideal Applications
High Speed Recovery for Competitive Off Road Use
This winch is ideal for:
- Race buggies and UTV competition vehicles
- High speed recovery scenarios
- Lightweight expedition builds
- Custom off road performance platforms
FREQUENTLY ASKED QUESTIONS
What makes the RS9 S different from standard winches
It is designed for high speed recovery with a compact short drum chassis, prioritising fast line speed and reduced weight over traditional bulky designs.
Can it still handle full 9000lb recovery loads
Yes, it retains full rated 9000lb pulling capacity despite the compact design.
Is this suitable for daily touring vehicles
It is primarily designed for performance and competition use rather than general touring or heavy utility recovery.
Does the short drum reduce rope capacity
No, it uses a performance optimised layout designed specifically for race applications while maintaining effective working rope length.
Is professional installation required
Yes, due to performance tuning and compact mounting requirements, professional installation is recommended.
Why Choose Carbon Offroad RS9 S 9000lb Short Drum Winch
The RS9 S delivers a specialist combination of high speed recovery performance, compact design, and lightweight construction for competitive off road environments.
It is built for operators who need maximum recovery speed, minimal weight impact, and reliable performance in high stress racing or performance off road conditions.
