Description
How the HSP Load Slide Works
The HSP Load Slide is a retractable Ford Ranger Super Duty tub slider that mounts to the tub floor and slides out over the tailgate when you need access to your cargo. The platform rides on heavy-duty structural steel rails and extends 75 % beyond the tub opening, bringing your gear to you rather than requiring you to reach or climb in.
HSP custom cuts every Load Slide platform using CNC routing machines in Australia. The platform contours around the wheel arches of your specific Super Duty tub rather than using a flat universal sheet that wastes space around the arches and leaves gaps at the sides.
HSP Ford Ranger Super Duty Load Slide Specifications
Specification | Detail |
Vehicle | Ford Ranger Super Duty 2025+ |
Extension | 75 percent beyond the tub |
Weight capacity | 250kg at full extension, dispersed weight |
Operation | Single-point handle |
Latching positions | Multiple positions approximately every 20 centimetres |
Platform height | 116mm from platform bottom to tub floor |
Surface | Hexa Birch anti-slip film, hexagonal pattern, DIN 51130 R10 rated |
Side rails | Custom cut, heavy duty, detachable |
Construction | Heavy-duty structural steel |
Custom cut | Yes, CNC cut in Australia to vehicle-specific tub dimensions |
Canopy compatible | Yes |
Manufacture | Australian made |
Waterproofing | Not designed for open tub use — requires canopy, roller cover or hard lid |
75% Extension
Most tray slides extend between 50 and 60 percent beyond the tub. The HSP Load Slide extends 75 percent, which means more of your cargo comes out to you rather than staying at the front of the tub where you cannot reach it without climbing in. The single-point handle releases and latches the slide in one motion. Latching positions sit approximately every 20 centimetres along the extension range, giving you a secure stop at any point rather than committing to full extension or full retraction only. This matters for owners who load different sized items regularly. A shorter extension suits smaller items near the tailgate. Full extension suits long items stored at the front of the tub.
Custom Cut Platform
Every HSP Ford Ranger Super Duty tub tray slide platform is cut specifically for the Super Duty tub using CNC routing machines in Australia. The platform wraps around the wheel arch positions rather than sitting flat across them. A universal flat platform loses the space above each wheel arch to gaps and wasted areas. The HSP custom cut platform fills these areas with a contoured edge, giving you usable surface right up to the arch without the platform rocking or lifting at the sides. This also means the platform sits flush against the tub walls, which prevents cargo from sliding under the gaps and becoming difficult to retrieve.
Hexa Anti-Slip Surface
The HSP Load Slide uses a Hexa Birch surface with an anti-slip film and hexagonal pattern rated to DIN 51130 R10. This is a German industrial standard for slip resistance on working surfaces. The hexagonal pattern grips the base of containers, toolboxes and camping gear during driving and when the slide is extended at a campsite or worksite. It also resists abrasion from heavy equipment being dragged across it during loading and unloading. The surface cleans with a damp cloth. HSP recommends fully extending the slide and blowing out any debris from underneath the platform regularly to keep the slide mechanism running smoothly.
Heavy Duty Detachable Side Rails
The HSP Load Slide includes custom cut heavy duty side rails that run along both sides of the platform. The rails act as a barrier to stop cargo sliding off the sides during extension and retraction. The rails are detachable. When you need to load an oversized item that is wider than the platform, remove the rails and the full platform width is available without obstruction. The rail mounting points also serve as anchor points for straps and tie downs. HSP recommends using the side rails as anchor points for any fragile items rather than relying on the anti-slip surface alone.
Canopy and Roller Cover Compatibility
The HSP Load Slide mounts inside the tub and does not affect the fit of a canopy or roller cover above it. The slide operates independently of whatever cover sits above it. The Load Slide is not designed for use in an open tub exposed to weather. It suits owners who run a canopy, HSP Roll R Cover, hard lid or other tub cover above it. The cover protects the slide mechanism and the Hexa surface from rain, dust and UV exposure. If you want both an HSP roller cover and the load slide fitted together, call us on (02) 4058 1911 to book a combined fitting appointment at our Cardiff workshop. For the HSP Roll R Cover Ford Ranger Super Duty visit our dedicated product page.
HSP Load Slide Installation in Newcastle
We install every HSP Ford Ranger Super Duty tray slide at our Cardiff workshop on Munibung Road. Our technicians confirm correct platform fit for your specific Super Duty tub, mount the slide rails to the tub floor and check full extension and retraction before your vehicle leaves our workshop. The HSP Load Slide includes all hardware for installation. Having our team fit it means the rail alignment is confirmed correct from the first use and any canopy or roller cover compatibility is checked before you drive away.
Buy Ford Ranger Super Duty Tray Slide in Newcastle
Call us on (02) 4058 1911 to confirm current stock of the HSP Load Slide for Ford Ranger Super Duty and get a fixed quote covering supply and fitting at our Cardiff workshop. Newcastle and Hunter Valley Ford Ranger Super Duty owners have trusted our Cardiff workshop for HSP accessories and 4WD fitouts for over ten years. Read our Google reviews from real local customers before booking. Get a free quote online or call us Monday to Friday 8am to 5pm and Saturday 9am to 1pm.
FREQUENTLY ASKED QUESTIONS
Where can I buy a Ford Ranger Super Duty tray slide in Newcastle?
Opposite Lock Cardiff on Munibung Road in Cardiff, Newcastle stocks and fits the HSP Load Slide tray slide for the Ford Ranger Super Duty 2025. We are a licensed and authorised HSP dealer and installer in Newcastle. Call us on (02) 4058 1911 to confirm current stock and book your installation. We are open Monday to Friday 8am to 5pm and Saturday 9am to 1pm.
How far does the HSP Load Slide extend beyond the Ford Ranger Super Duty tub?
The HSP Load Slide extends 75 percent beyond the Ford Ranger Super Duty tub. The single-point handle releases and latches the slide at multiple positions approximately every 20 centimetres along the extension range. The platform sits 116mm above the tub floor at full extension. Call us on (02) 4058 1911 to confirm the correct setup for your specific tub configuration.
How much weight does the HSP Ford Ranger Super Duty tray slide carry?
The HSP Load Slide carries 250kg of dispersed weight at full extension. The platform uses heavy-duty structural steel construction throughout. HSP recommends using the side rails as anchor points for fragile items rather than relying on the anti-slip surface alone. Call us on (02) 4058 1911 to confirm the load capacity for your specific cargo requirements.
Is the HSP Load Slide waterproof for the Ford Ranger Super Duty?
The HSP Load Slide is not designed for use in an open tub exposed to weather. It suits owners who run a canopy, HSP Roll R Cover, hard lid or roller shutter above it. The cover protects the slide mechanism and the Hexa surface from rain, dust and UV exposure. Call us on (02) 4058 1911 to confirm compatibility with your current or planned tub cover setup.
Does the HSP Ford Ranger Super Duty tray slide work with a canopy?
Yes. The HSP Load Slide mounts inside the tub and operates independently of whatever cover sits above it, including canopies, the HSP Roll R Cover and hard lids. The slide does not affect the fit of the cover above it. Call us on (02) 4058 1911 to confirm compatibility with your specific canopy or cover and book a combined fitting appointment if needed.
