Description
SAFARI SS385HF 4X4 SNORKEL FOR LAND ROVER DISCOVERY 4 DIESEL – MAXIMUM AIRFLOW, ENGINE PROTECTION & OFF-ROAD RELIABILITY
The Safari Land Rover Discovery 4 snorkel system is designed to improve engine protection and airflow efficiency in demanding off-road environments. By relocating the intake higher on the vehicle, the snorkel significantly reduces the risk of dust ingestion during desert driving and prevents water entering the air intake during river crossings.
The aerodynamic Safari air ram channels cooler outside air into the snorkel body while separating moisture before it reaches the air filter housing. This helps ensure reliable engine performance in dusty tracks, muddy trails, and extreme weather conditions.
KEY FEATURES OF SAFARI SS385HF SNORKEL
Australian designed, moulded, and manufactured by Safari Automotive
Raised air intake protects the engine from dust, debris, and water
Increased airflow for Land Rover Discovery 4 diesel engines
Advanced water-separating air ram technology
Durable UV-stable cross-linked polyethylene construction
Heavy-duty snorkel body designed for extreme off-road environments
Comprehensive fitting guide with installation templates included
VEHICLE COMPATIBILITY
Vehicle | Engine | Year | Safari Part Number |
Land Rover Discovery 4 | All Diesel Engines | 10/2009 Onwards | SS385HF |
SNORKEL SYSTEM DESIGN
The Safari SS385HF snorkel system raises the intake point to roof height, allowing the engine to breathe cooler and cleaner air. This design significantly reduces dust ingestion when driving on unsealed roads and protects the engine during water crossings or heavy rainfall.
The integrated high-efficiency air ram optimizes airflow while simultaneously removing rainwater from the intake stream before it reaches the air cleaner assembly.
CONSTRUCTION AND DURABILITY
Safari snorkels are built to withstand extreme environmental conditions. The snorkel body and air ram are manufactured from UV-stable cross-linked polyethylene, providing excellent resistance to heat, sunlight, and impact damage.
The thick-wall construction ensures maximum structural strength, allowing the snorkel to perform reliably in tough off-road environments, remote overland expeditions, and harsh climates.
SAFARI SS385HF SNORKEL KIT PARTS LIST
Safari Snorkel Land Rover Discovery 4 4×4 Kit – Parts List
Land Rover Discovery 4 4WD Snorkel for 10/2009 Onwards All Diesel Models – Safari Automotive Land Rover Discovery 4 4×4 Snorkel Part Number SS385HF
Actual model not shown.
| ITEM | PART NO. | DESCRIPTION | QTY |
|---|---|---|---|
| 1 | 830-133-800 | BODY – SNORKEL | 1 |
| 2 | 000-135-800 | 3½” AIR RAM ASSEMBLY | 1 |
| 3 | 830-032-800 | BRACKET – UPPER MOUNTING | 1 |
| 4 | 000-002-100 | BOLT – HEX – 6mm x 1.0 x 14mm (SEMS) | 3 |
| 5 | 000-958-350 | POP RIVET – 4.8mm x 14mm | 8 |
| 6 | 000-110 | STUD – S/S – 8mm x 1.25 x 25mm O/L | 2 |
| 7 | 000-311 | WASHER – BODY – 8mm x 30mm | 2 |
| 8 | 000-205 | NUT – NYLOC – 8mm x 1.25mm | 2 |
| 9 | 000-108 | STUD – S/S 6mm x 1.0 x 25mm OL | 3 |
| 10 | 000-321 | WASHER – BODY – 6mm x 20mm | 3 |
| 11 | 000-204 | NUT – NYLOC – 6mm x 1.0mm | 3 |
| 12 | 830-023-800 | DUCT – CONNECTING | 1 |
| 13 | 000-887-075 | CUFFED HOSE – 82mm ID x 750mm | 1 |
| 14 | 000-909 | CLAMP HOSE – 80/100mm | 2 |
| 15 | 830-410-800 | SEAL – FOAM | 1 |
| 16 | 830-017-800 | TEMPLATE – GUARD PANEL | 1 |
| 17 | 830-217-800 | TEMPLATE – INNER GUARD | 1 |
| 18 | 830-217-825 | TEMPLATE – MOUNTING BRACKET | 1 |
| 19 | 830-217-850 | TEMPLATE – ‘A’ PILLAR TRIM | 1 |
| 20 | 000-914/B | HOSE – CLAMP – SIZE 56 (BLACK) | 1 |
INSTALLATION GUIDE
The Safari SS385HF snorkel kit includes detailed installation instructions along with precision templates for the guard panel, inner guard, mounting bracket, and A-pillar trim. These templates help ensure accurate placement and alignment with the factory air intake system.
Proper installation ensures a sealed air intake system for maximum airflow and engine protection.
FREQUENTLY ASKED QUESTIONS
Is the Safari SS385HF snorkel compatible with all Discovery 4 diesel models?
Yes. This snorkel is designed for Land Rover Discovery 4 diesel models manufactured from October 2009 onwards.
Does installing a snorkel improve engine protection?
Yes. The raised air intake helps protect the engine from dust, debris, and water ingestion during off-road driving and extreme weather.
Does the snorkel kit include all installation hardware?
Yes. The kit includes the snorkel body, air ram, brackets, hoses, clamps, hardware, and installation templates required for installation.
Is the SS385HF a genuine Safari snorkel product?
Yes. The SS385HF is a genuine Safari Automotive snorkel designed and manufactured in Australia.
